Application

1. Suitable for transferring clean water or other liquids which are not chemically aggressive to the pump components.
2. Widely used in living water supply, garden irrigation, vegetable greenhouse water supply, breeding industry water supply and drainage, pipeline boosting, etc.

Features

1. Centrifugal pump with high efficiency
2. Reliable, economical and simple to use

Operating conditions

The pump should be installed in a covered area, protected against the bad weather.
1. Maximum Liquid temperature:+40℃
2. Maximum Ambient temperature:+40℃
3. Maximum Suction: 8m
4. Protection class: Ip44
5. Insulation class: B

Motor and pump

1. Copper winding motor
2. Single-phase: 220V-240V/50Hz
3. Three-phase: 380V-415V/50Hz
4. Single-phase with capacitor and thermal overload protection.

Optional available one request

1. Special request for mechanical seal, bearing or shaft

2. Other voltages or frequency: 60HZ
